High Efficiency Feed Pellet Production Line 256kw Animal Feed Pellet Machines

High Efficiency Feed Pellet Production Line

Feed Pellet Production Line 256kw

256kw Animal Feed Pellet Machines

Tempat asal:

Cina

Nama merek:

Zhongdebao

Sertifikasi:

CE BV

Nomor model:

EWPL-1TPH

Hubungi kami

Permintaan Penawaran

Rincian Produk

Aplikasi:

mesin pakan pelet pakan ternak rumput domba

Layanan purna jual disediakan:

Insinyur tersedia untuk melayani mesin di luar negeri, Instalasi lapangan, komisioning dan pelatihan

Tegangan:

380V/50HZ, 380v, 50hz, 380V/50HZ/Tiga Fase, 220V/50HZ/Fase Tunggal atau Ubah Sesuai Kebutuhan

Daya (w):

45KW, 256kw, 195kw, 80KW, 22/30/55/75/90kw

Jaminan:

1 Tahun, satu tahun, 12 BULAN

Berat:

500kg, 6000kg, 1200kg, 2-10TON, 2000

Dimensi (L * W * H):

30000*5000*3500mm, 3.2*1.1*2m, 21*2*3m, 3.5x1.05x1.96m, Sesuai kapasitas

Kondisi:

Baru

Kapasitas:

100kg/jam 200kg/jam 500kg/jam 1000kg/jam hingga 20ton/jam

Bahan:

Baja paduan baja karbon

Motor:

Simens, motor Cina atau Simense

Nama Produk:

lini produksi pelet kayu biomassa

Warna:

biru putih hijau warna apapun bisa disesuaikan

Jenis:

lini produksi pelet kayu biomassa

Bahan baku:

wood chips Eucalyptus pine birch poplar Rice husks, peanut husks, melon seed husks, bamboo shavin

Motor utama:

22kw 30kw 37kw 55kw

Keluaran:

300kg/jam 500kg/jam 800kg/jam 1000kg/jam 1,5ton/jam 1,8-2ton/jam 2,5-3ton/jam

Tahun:

2023

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order

1

Harga

price negotiable

Kemasan rincian

langsung dimuat dalam wadah atau dikemas dengan kotak kayu

Waktu pengiriman

5-8 Hari Kerja

Syarat-syarat pembayaran

L/C, T/T, Serikat Barat

Menyediakan kemampuan

100 set per minggu

Produk-produk terkait

Video

CE 3000kg/H Lini Produksi Pellet Pakan Hewan Perundingan Warna

Dapatkan Harga Terbaik

Video

Lini Produksi Pellet Umpan Efisiensi Tinggi Campuran Penghancur Bersih Granulat Paket Layar Dingin

Dapatkan Harga Terbaik

Video

Lini Produksi Pellet Umpan Efisiensi Tinggi Campuran Renyah Crush Granulate Cold Screen & Pack

Dapatkan Harga Terbaik

Video

Lini Produksi Pelet Pakan 2 Ton/Jam Untuk Pakan Unggas Ternak

Dapatkan Harga Terbaik

Hubungi kami

86-371-86546711

Hubungi sekarang

Deskripsi Produk

1-20TPH chicken poultry livestock feed pellet production line

Production application :

Type : Animal feed pellet production line

Capacity : 1-20TPH

Pellet size : 1.5-12mm ( 1.5-6mm generally for animal feed )

Application : Can be used for poultry , livestock , ruminants and aquatic pellet feed production .

HKJ Series Ring die pellet machine models :

Model

Main Power

Feeder Power

Conditioner Power

Dia.of Ring Die

Pellet Size

Capacity

HKJ-250

22KW

0.55KW

1.5KW

250mm

φ1.5-12.0mm

1-2T/H

HKJ-320

37KW

1.5KW

2.2KW

320mm

φ1.5-12.0mm

3-5T/H

HKJ-350

55KW

1.5KW

3.0KW

350mm

φ1.5-12.0mm

5-8T/H

HKJ-420

110KW

2.2KW

7.5KW

420mm

φ1.5-12.0mm

8-12T/H

HKJ-508

132/160KW

2.2KW

11KW

520mm

φ1.5-12.0mm

12-18T/H

This one is double conditioners ring die pellet machine

This above horizontal HKJ-250 chicken feed pellets line exported to Africa .

Process :

Main machines :

Function :

Crushing section

Hammer mill

Crush raw materials into powders

Batching and Mixing section Mixer batching manual or automatic then mixing the crushed powder evenly for later making the animal feed pellets more comprehensive and nutritious.

Pelleting section

horizontal ring die pellet machine

Press mixed raw materials into pellets

Cooling section

counterflow cooling machine

Reduce temperature to room termperature and reduce moisture of pellets for later easily storage

Finished pellets crumbling system roller crumbling machine for crumbling finished pellets to very smaller particles for baby chick feed

Packing section

Automatic packing machine

Weigh and pack the final pellets into bags and sewing the bags

Electric control

Electric control cabinet

Control the complete line

Tag：

Lini Produksi Pelet Pakan Efisiensi Tinggi

Pabrik Pakan Ternak 1Ton/jam

Mesin Pembuat Pelet 2.5mm Untuk Pakan Unggas

Kirimkan pertanyaan Anda langsung kepada kami

HKJ Series Ring die pellet machine models :
Model	Main Power	Feeder Power	Conditioner Power	Dia.of Ring Die	Pellet Size	Capacity
HKJ-250	22KW	0.55KW	1.5KW	250mm	φ1.5-12.0mm	1-2T/H
HKJ-320	37KW	1.5KW	2.2KW	320mm	φ1.5-12.0mm	3-5T/H
HKJ-350	55KW	1.5KW	3.0KW	350mm	φ1.5-12.0mm	5-8T/H
HKJ-420	110KW	2.2KW	7.5KW	420mm	φ1.5-12.0mm	8-12T/H
HKJ-508	132/160KW	2.2KW	11KW	520mm	φ1.5-12.0mm	12-18T/H

Process :	Main machines :	Function :
Crushing section	Hammer mill	Crush raw materials into powders
Batching and Mixing section	Mixer	batching manual or automatic then mixing the crushed powder evenly for later making the animal feed pellets more comprehensive and nutritious.
Pelleting section	horizontal ring die pellet machine	Press mixed raw materials into pellets
Cooling section	counterflow cooling machine	Reduce temperature to room termperature and reduce moisture of pellets for later easily storage
Finished pellets crumbling system	roller crumbling machine	for crumbling finished pellets to very smaller particles for baby chick feed
Packing section	Automatic packing machine	Weigh and pack the final pellets into bags and sewing the bags
Electric control	Electric control cabinet	Control the complete line
